| Price： | 1650Yuan |
|---|---|
| Original Price： | 1650Yuan |
| Discount Price： | Yuan |
| Security Code： | No |
|---|---|
| Add Time： | 2015-09-11 03:37:10 |
| Recommendation： |  |
Specifications
1.first brand of heavy duty truck in china
2.all original spare parts
3.individual needs can be meet
4.professional service
summary parameter
|
Model |
SX3254**** |
mark |
|
Drive type |
6*4 |
|
|
Wheelbase(mm) |
3800+1350 |
Optional |
|
Weight |
|
|
|
Complete kerb mass(kgs) |
14500 |
|
|
GVW (kgs) |
32500 |
|
|
Dimensions |
|
|
|
length (mm) |
8329 |
|
|
width(mm) |
2490 |
|
|
Height (mm) |
3450 |
|
|
Platform dimension |
5800*2300*1100 |
optional |
|
Performance |
|
|
|
Max.speed (km/h) |
74 |
|
|
Min.turning circle (m) |
17 |
|
|
Engine |
|
|
|
Brand |
WEI CHAI |
|
|
Model |
WD615 |
optional |
|
Power(kw/HP) |
260-380 |
optional |
|
Max.Torque (N.m )/rpm |
1500/1200—1600 |
|
|
Displacement (L) |
9.726 |
|
|
Emmission Standards |
Euro Ⅱ |
|
|
Transmission |
|
|
|
Brand |
FAST |
|
|
Model |
RT-11509C/9JS135/8JS118 |
Optional |
|
Control type |
manual |
|
|
clutch |
|
|
|
type |
Spring plate, diaphragm spring |
|
|
Diameter(mm) |
Φ430 |
|
|
brakes |
|
|
|
type |
drum |
|
|
Service brake |
With dual-circuit compressed air brake |
|
|
option |
Jacobs, ABS |
|
|
Steering |
|
|
|
type |
Integral circuiting ball power steering |
|
|
option |
ZF |
|
|
Tyres |
|
|
|
type |
11.00-20 |
|
|
option |
12.00-20/11.00R20/12.00R20 |
|
|
Fuel tank |
|
|
|
Tank capacity(L) |
300 |
|
|
material |
aluminum |
|
|
Electrics |
|
|
|
type |
24V |
|
|
battery |
2*180A |
|
|
cab |
|
|
|
type |
MAN F2000 mid-lengthened flat roof |
|
|
equipments |
2 rear windows, mechanical clerestory, hydraulic suspension cab, hydraulic air with seatbelts, one sleeping bed ,hydraulic reversal cab, with USB , can play radio broadcasting and audio in MP3 format. |
|
|
option |
Electric windows, electricity heated rear-view mirror, GPS or CD, tachograph; 2 points air suspension ,A/C, air suspension driver seat with handle and seatbelts, cruise control system, car phone, electricity reversal cab |
